The SAP Single Sign-On application enables users to log in once to gain secure access to all the software they require throughout the day with no need to log in again ,with SAP Single Sign-On
There are several process to set up setup SSO in On premise system as well as on cloud, here we will discuss SSO setup between Azure and SAP on Public Cloud using IdP
There are two primary options in which SAP Identity Authentication Services and Microsoft Entra ID can be integrated:
Microsoft Entra ID as the Identity Provider (IdP): This scenario makes Microsoft Entra ID the central authentication hub, with users logging into SAP applications using their Microsoft Entra ID credentials.
SAP IAS as the IdP: In this case, SAP IAS becomes the primary authentication source, with users logging into Microsoft Entra ID applications using their SAP credentials.
Recently I got opportunity to setup SSO between Microsoft Entra ID (formerly known as Microsoft Azure Active Directory or Azure AD) , SAP IAS and SuccessFactors on SAP on Public Cloud (Grow with SAP) using SAP IAS as the IdP.
Below are step to configure SSO between Azure ,IAS and Success Factor.
1- Configure SAP IAS
Login on IAS system go to Applications and Resources -> Tenant Settings ->Single Sign On-> SAML 2.0 Configuration the download metadata file on you system share this file to Azure team and ask for Federation Metadata XML
2- Configure Microsoft Entra ID
This setp should be perform by azure admin system by following step
Create an Application in Microsoft Entra ID: This application represents your SAP IAS instance. Login to https://portal.azure.com and setup the Microsoft Entra ID.
Click Add -> Enterprise Applications
By default, Microsoft Azure supports variety of applications. Search with SAP Cloud Identity Services. Select the SAP Cloud Identity Services and click on create.
We will be using the SAML Metadata file to setup the trust between Microsoft Entra ID and SAP Identity Authentication service (IAS). Click on Setup Single Sign-On.
Choose SAML as the SSO method and upload the SAP IAS metadata file.
After saving the application you can download the Federation Metadata XML file which we will add to the SAP Cloud Identity Services (IAS).
3- Configure Federation metadata on IAS
Login on IAS system and click identity Provider and select Corporate identity Provider
Click on create
Fill are require data
Click on create it will create entry in Identity provider
Now click on SAML2.0 Configuration
And upload azure xml file
All setting between Azure and IAS system has been done.You can check SSO connection via login on IAS system ,it will pick Azure authentication and will login without asking password on IAS system
Now going to setup SSO connection between IAS and managed application system here I will setup connection between IAS to success factor, you can choose other system depend on requirement
Login on IAS system and click on Application & Resources and select SuccessFactors system
Now select single Sign-on and check Subject Name Identifier it should be as below
select single Sign-on and check Default Name ID Format
Check attribute it should be as below
Now maintain domain in Conditional Authentication as per below
All setting has been completed for SF system
Now login to sf provision url and enable SSO
Now test sso from SF system it will automatically login on system without login page
Reference
Simplify SSO with Microsoft Entra ID (Azure AD) & … – SAP Communityhttps://learn.microsoft.com/en-us/entra/identity/saas-apps/sap-hana-cloud-platform-identity-authentication-tutorial
