Introduction

The ABAP RESTful Application Programming Model (RAP) provides a powerful way to build modern SAP Fiori applications using behavior definitions, CDS views, and OData services.

One common requirement in business applications is allowing users to execute actions on one or multiple records while providing additional input through a dialog popup. In many scenarios, this input should be selected from a predefined list of values rather than entered manually.

A typical example is updating the category of one or more products. Users should be able to trigger an action, choose a valid category from a value help dialog, and apply the selected category to all chosen records.

This blog demonstrates how to implement an RAP Action Parameter with Value Help using a CDS Abstract Entity, CDS Value Help View, and Behavior Action. The result is a Fiori Elements application where users can execute an action and select values through standard SAP F4 help.

What are RAP Action Parameters?

Actions in RAP allow developers to execute custom business logic that goes beyond standard Create, Update, and Delete operations.

An action can:

Execute custom business logicUpdate one or multiple recordsTrigger validationsOpen parameter dialogs for user input

When an action requires user input, RAP automatically generates a dialog popup using an Abstract Entity.

This makes actions ideal for scenarios such as:

Approving business documentsAssigning categoriesUpdating statusesTriggering business processes

Real-Time Business Scenario: Mass Category Assignment

Consider a product management application.

Business users maintain products and their categories.

Examples:

Product ID Product Name Category

P1001LaptopELECP1002Office ChairFURNP1003T-ShirtCLTH

A user selects multiple products and wants to update their category simultaneously.

Instead of editing each product individually:

Select one or more productsClick Set CategoryChoose a category from F4 HelpConfirm the action

All selected products are updated automatically.

The Problem

If the category field is entered manually:

Users may enter invalid valuesValidation becomes difficultUser experience is poorData consistency cannot be guaranteed

Example:

ELEC ✔ Valid
FURN ✔ Valid
ABCD ✖ Invalid
XYZ1 ✖ Invalid

Without a value help mechanism, users can easily enter incorrect data.

The Solution

To solve this problem, we implement:

A Category Master tableA CDS Value Help ViewA CDS Abstract Entity for action parametersA RAP Action with parameter supportA Fiori Elements Value Help dialog

The action parameter field is linked to the value help CDS entity using:

@Consumption.valueHelpDefinition

This automatically generates:

F4 HelpSearch dialogValue validationUser-friendly selection experience

Implementation Using RAP Action Parameter Value Help

Step 1: Create Category Master Table

Create a database table to store available product categories.

@EndUserText.label : ‘Product Category Table’
@AbapCatalog.enhancement.category : #NOT_EXTENSIBLE
@AbapCatalog.tableCategory : #TRANSPARENT
@AbapCatalog.deliveryClass : #A
@AbapCatalog.dataMaintenance : #RESTRICTED
define table zprod_category {

key client : abap.clnt not null;
key category_id : abap.char(4) not null;
category_name : abap.char(40);

}

This table acts as the master source for the value help.

Step 2: Create Product Table

Create a product table containing:

Product IDProduct NameCategoryAudit fields

@EndUserText.label : ‘Product Table’
@AbapCatalog.enhancement.category : #NOT_EXTENSIBLE
@AbapCatalog.tableCategory : #TRANSPARENT
@AbapCatalog.deliveryClass : #A
@AbapCatalog.dataMaintenance : #ALLOWED
define table zproduct_s {

key client : abap.clnt not null;
key product_id : abap.char(10) not null;
product_name : abap.char(40);
category : abap.char(4);
created_by : abp_creation_user;
created_at : abp_creation_tstmpl;
last_changed_by : abp_locinst_lastchange_user;
last_changed_at : abp_locinst_lastchange_tstmpl;
local_last_changed_at : abp_locinst_lastchange_tstmpl;

}

This table stores the transactional product data.

Step 3: Create Value Help CDS View

Create a CDS View Entity that exposes category information.

@AbapCatalog.viewEnhancementCategory: [#NONE]
@AccessControl.authorizationCheck: #NOT_REQUIRED
@EndUserText.label: ‘Category Value Help’
@Metadata.ignorePropagatedAnnotations: true
@ObjectModel.usageType:{
serviceQuality: #X,
sizeCategory: #S,
dataClass: #MIXED
}

define view entity ZI_CategoryVH
as select from zprod_category
{
key category_id as CategoryId,
category_name as CategoryName
}

Explanation:

Provides the source for value helpSupplies category IDs and descriptionsUsed by both RAP and Fiori Elements

Step 4: Create Root Interface View

Create the RAP Root Interface View.

@AccessControl.authorizationCheck: #NOT_REQUIRED
@EndUserText.label: ‘Product Interface View’
@Metadata.ignorePropagatedAnnotations: true
define root view entity ZI_PRODUCT_S as select from zproduct_s
{

key product_id as ProductId,
product_name as ProductName,
category as Category,

@Semantics.user.createdBy: true
created_by as CreatedBy,

@Semantics.systemDateTime.createdAt: true
created_at as CreatedAt,

@Semantics.user.lastChangedBy: true
last_changed_by as LastChangedBy,

@Semantics.systemDateTime.lastChangedAt: true
last_changed_at as LastChangedAt,

@Semantics.systemDateTime.localInstanceLastChangedAt: true
local_last_changed_at as LocalLastChangedAt
}

This view represents the Product business object.

Step 5: Create Projection View

Create the Projection View exposed to Fiori.

@AccessControl.authorizationCheck: #NOT_REQUIRED
@EndUserText.label: ‘Product Projection View’
@Metadata.ignorePropagatedAnnotations: true
@Metadata.allowExtensions: true
define root view entity ZC_PRODUCT
provider contract transactional_query
as projection on ZI_PRODUCT_S
{
key ProductId,
ProductName,
@Consumption.valueHelpDefinition: [{
entity: {
name: ‘ZI_CATEGORYVH’,
element: ‘CategoryId’
}
}]
Category,
CreatedBy,
CreatedAt,
LastChangedBy,
LastChangedAt,
LocalLastChangedAt
}

This enables F4 Help on the Category field.

Step 6: Create Abstract Entity for Action Parameters

The action dialog parameters are defined using a CDS Abstract Entity.

@EndUserText.label: ‘Parameter for Set Category Action’
define abstract entity ZA_SETCATEGORY_PARAM
{
@EndUserText.label: ‘New Category’
@Consumption.valueHelpDefinition: [{
entity : {
name : ‘ZI_CATEGORYVH’,
element : ‘CategoryId’
},
useForValidation: true
}]
NewCategory : abap.char(4);

}

Explanation:

Generates the popup fieldProvides F4 helpEnables automatic validation

Important:

useForValidation: true

prevents invalid values from being entered.

Step 7: Create Interface Behavior Definition

Define the RAP Action.

managed implementation in class zbp_i_product_s unique;
strict ( 2 );

define behavior for ZI_PRODUCT_S alias Product
persistent table zproduct_s
lock master
authorization master ( instance )
etag master LastChangedAt
{
create;
update;
delete;

field ( readonly ) ProductId, CreatedBy, CreatedAt,
LastChangedBy, LastChangedAt,
LocalLastChangedAt;

field ( mandatory ) ProductName;

action setCategory parameter ZA_SETCATEGORY_PARAM
result [1] $self;

Step 8: Implement Action Logic

In the behavior implementation class:

METHOD setcategory.

The implementation:

Reads selected productsRetrieves action parameter valueUpdates category fieldReturns updated records

The selected category is obtained from:

keys[ … ]-%param-NewCategoryCLASS lhc_Product DEFINITION INHERITING FROM cl_abap_behavior_handler.
PRIVATE SECTION.

METHODS get_instance_authorizations FOR INSTANCE AUTHORIZATION
IMPORTING keys REQUEST requested_authorizations FOR Product RESULT result.

METHODS setCategory FOR MODIFY
IMPORTING keys FOR ACTION Product~setCategory RESULT result.

ENDCLASS.

CLASS lhc_Product IMPLEMENTATION.

METHOD get_instance_authorizations.
ENDMETHOD.

METHOD setCategory.

” Read current product records
READ ENTITIES OF zi_product_s IN LOCAL MODE
ENTITY Product
FIELDS ( ProductId Category )
WITH CORRESPONDING #( keys )
RESULT DATA(lt_products).

” Update category field for each selected product
MODIFY ENTITIES OF zi_product_s IN LOCAL MODE
ENTITY Product
UPDATE FIELDS ( Category )
WITH VALUE #(
FOR ls_prod IN lt_products
(
%tky = ls_prod-%tky
Category = keys[ KEY entity
%key = ls_prod-%key
]-%param-NewCategory
)
)
REPORTED DATA(lt_reported).

” Return updated records as action result
READ ENTITIES OF zi_product_s IN LOCAL MODE
ENTITY Product
ALL FIELDS
WITH CORRESPONDING #( keys )
RESULT DATA(lt_result).

result = VALUE #(
FOR ls_res IN lt_result
( %tky = ls_res-%tky
%param = ls_res )
).
ENDMETHOD.

ENDCLASS.

Step 9: Create Projection Behavior Definition

Expose the action:

projection;
strict ( 2 );

define behavior for ZC_PRODUCT //alias <alias_name>
{
use create;
use update;
use delete;

use action setCategory;
}

Step 10: Create Metadata Extension

Add UI annotations.

@Metadata.layer: #CORE

annotate entity ZC_PRODUCT with
{
@ui.facet: [
{
id: ‘ProductInfo’,
type: #IDENTIFICATION_REFERENCE,
label: ‘Product Information’,
position: 10
}
]

@ui.lineItem: [
{ position: 10, label: ‘Product ID’ },
{ type: #FOR_ACTION, dataAction: ‘setCategory’,
label: ‘Set Category’, position: 40 }
]
@ui.identification: [{ position: 10 }]
@ui.selectionField: [{ position: 10 }]
ProductId;

@ui.lineItem: [{ position: 20, label: ‘Product Name’ }]
@ui.identification: [{ position: 20 }]
ProductName;

@ui.lineItem: [{ position: 30, label: ‘Category’ }]
@ui.identification: [{ position: 30 }]
Category;

}

Step 11: Create Service Definition

Expose both entities.

@EndUserText.label: ‘Product Service’
define service ZSD_PRODUCT {
expose ZC_PRODUCT as Product;
expose ZI_CategoryVH as CategoryVH;
}

Important:

Many developers forget to expose the value help entity.

Without exposing:

ZI_CATEGORY_VH

the F4 dialog will not display any data.

Step 12: Create Service Binding

Create:

OData V4 – UI

service binding.

Activate and Publish the service.

Result

Once the application is launched, users can:

1. Select Products

☑ P1001 Laptop
☑ P1002 Office Chair

2. Click Set Category

[ Set Category ]

3. Action Dialog Opens

Set Category

New Category [ ] 🔍

4. Open Value Help

ELEC Electronics
FURN Furniture
CLTH Clothing
FOOD Food & Beverages

5. Choose a Category

Example:

ELEC

6. Confirm

7. RAP Action Executes

Selected records are updated automatically.

8. List Refreshes

P1001 Laptop ELEC
P1002 Office Chair ELEC

Success message:

Category updated successfully

Conclusion

In this blog, we explored how to implement RAP Action Parameters with Value Help using a CDS Abstract Entity.

We discussed a real-world business scenario where users need to update product categories for multiple records while ensuring only valid values can be selected.

By combining a CDS Value Help View, Abstract Entity, RAP Action, and Fiori Elements annotations, we were able to create a user-friendly action dialog with built-in F4 help and validation.

This approach provides a reusable pattern for implementing parameterized actions in RAP and can easily be extended for approval processes, status updates, assignment actions, and many other business scenarios while maintaining a clean and scalable design.

IntroductionThe ABAP RESTful Application Programming Model (RAP) provides a powerful way to build modern SAP Fiori applications using behavior definitions, CDS views, and OData services.One common requirement in business applications is allowing users to execute actions on one or multiple records while providing additional input through a dialog popup. In many scenarios, this input should be selected from a predefined list of values rather than entered manually.A typical example is updating the category of one or more products. Users should be able to trigger an action, choose a valid category from a value help dialog, and apply the selected category to all chosen records.This blog demonstrates how to implement an RAP Action Parameter with Value Help using a CDS Abstract Entity, CDS Value Help View, and Behavior Action. The result is a Fiori Elements application where users can execute an action and select values through standard SAP F4 help.What are RAP Action Parameters?Actions in RAP allow developers to execute custom business logic that goes beyond standard Create, Update, and Delete operations.An action can:Execute custom business logicUpdate one or multiple recordsTrigger validationsOpen parameter dialogs for user inputWhen an action requires user input, RAP automatically generates a dialog popup using an Abstract Entity.This makes actions ideal for scenarios such as:Approving business documentsAssigning categoriesUpdating statusesTriggering business processesReal-Time Business Scenario: Mass Category AssignmentConsider a product management application.Business users maintain products and their categories.Examples:Product ID Product Name CategoryP1001LaptopELECP1002Office ChairFURNP1003T-ShirtCLTHA user selects multiple products and wants to update their category simultaneously.Instead of editing each product individually:Select one or more productsClick Set CategoryChoose a category from F4 HelpConfirm the actionAll selected products are updated automatically.The ProblemIf the category field is entered manually:Users may enter invalid valuesValidation becomes difficultUser experience is poorData consistency cannot be guaranteedExample:ELEC ✔ Valid
FURN ✔ Valid
ABCD ✖ Invalid
XYZ1 ✖ InvalidWithout a value help mechanism, users can easily enter incorrect data.The SolutionTo solve this problem, we implement:A Category Master tableA CDS Value Help ViewA CDS Abstract Entity for action parametersA RAP Action with parameter supportA Fiori Elements Value Help dialogThe action parameter field is linked to the value help CDS entity using:@Consumption.valueHelpDefinitionThis automatically generates:F4 HelpSearch dialogValue validationUser-friendly selection experienceImplementation Using RAP Action Parameter Value HelpStep 1: Create Category Master TableCreate a database table to store available product categories.@EndUserText.label : ‘Product Category Table’
@AbapCatalog.enhancement.category : #NOT_EXTENSIBLE
@AbapCatalog.tableCategory : #TRANSPARENT
@AbapCatalog.deliveryClass : #A
@AbapCatalog.dataMaintenance : #RESTRICTED
define table zprod_category {

key client : abap.clnt not null;
key category_id : abap.char(4) not null;
category_name : abap.char(40);

}This table acts as the master source for the value help. Step 2: Create Product TableCreate a product table containing: Product IDProduct NameCategoryAudit fields @EndUserText.label : ‘Product Table’
@AbapCatalog.enhancement.category : #NOT_EXTENSIBLE
@AbapCatalog.tableCategory : #TRANSPARENT
@AbapCatalog.deliveryClass : #A
@AbapCatalog.dataMaintenance : #ALLOWED
define table zproduct_s {

}This table stores the transactional product data. Step 3: Create Value Help CDS ViewCreate a CDS View Entity that exposes category information.@AbapCatalog.viewEnhancementCategory: [#NONE]
@AccessControl.authorizationCheck: #NOT_REQUIRED
@EndUserText.label: ‘Category Value Help’
@Metadata.ignorePropagatedAnnotations: true
@ObjectModel.usageType:{
serviceQuality: #X,
sizeCategory: #S,
dataClass: #MIXED
}

define view entity ZI_CategoryVH
as select from zprod_category
{
key category_id as CategoryId,
category_name as CategoryName
}Explanation:Provides the source for value helpSupplies category IDs and descriptionsUsed by both RAP and Fiori ElementsStep 4: Create Root Interface ViewCreate the RAP Root Interface View.@AccessControl.authorizationCheck: #NOT_REQUIRED
@EndUserText.label: ‘Product Interface View’
@Metadata.ignorePropagatedAnnotations: true
define root view entity ZI_PRODUCT_S as select from zproduct_s
{

key product_id as ProductId,
product_name as ProductName,
category as Category,

@Semantics.user.createdBy: true
created_by as CreatedBy,

@Semantics.systemDateTime.createdAt: true
created_at as CreatedAt,

@Semantics.user.lastChangedBy: true
last_changed_by as LastChangedBy,

@Semantics.systemDateTime.lastChangedAt: true
last_changed_at as LastChangedAt,

@Semantics.systemDateTime.localInstanceLastChangedAt: true
local_last_changed_at as LocalLastChangedAt
}This view represents the Product business object. Step 5: Create Projection ViewCreate the Projection View exposed to Fiori.@AccessControl.authorizationCheck: #NOT_REQUIRED
@EndUserText.label: ‘Product Projection View’
@Metadata.ignorePropagatedAnnotations: true
@Metadata.allowExtensions: true
define root view entity ZC_PRODUCT
provider contract transactional_query
as projection on ZI_PRODUCT_S
{
key ProductId,
ProductName,
@Consumption.valueHelpDefinition: [{
entity: {
name: ‘ZI_CATEGORYVH’,
element: ‘CategoryId’
}
}]
Category,
CreatedBy,
CreatedAt,
LastChangedBy,
LastChangedAt,
LocalLastChangedAt
}This enables F4 Help on the Category field.Step 6: Create Abstract Entity for Action ParametersThe action dialog parameters are defined using a CDS Abstract Entity.@EndUserText.label: ‘Parameter for Set Category Action’
define abstract entity ZA_SETCATEGORY_PARAM
{
@EndUserText.label: ‘New Category’
@Consumption.valueHelpDefinition: [{
entity : {
name : ‘ZI_CATEGORYVH’,
element : ‘CategoryId’
},
useForValidation: true
}]
NewCategory : abap.char(4);

}Explanation:Generates the popup fieldProvides F4 helpEnables automatic validationImportant:useForValidation: trueprevents invalid values from being entered. Step 7: Create Interface Behavior DefinitionDefine the RAP Action.managed implementation in class zbp_i_product_s unique;
strict ( 2 );

define behavior for ZI_PRODUCT_S alias Product
persistent table zproduct_s
lock master
authorization master ( instance )
etag master LastChangedAt
{
create;
update;
delete;

field ( readonly ) ProductId, CreatedBy, CreatedAt,
LastChangedBy, LastChangedAt,
LocalLastChangedAt;

field ( mandatory ) ProductName;

action setCategory parameter ZA_SETCATEGORY_PARAM
result [1] $self;

mapping for zproduct_s corresponding
{
ProductId = product_id;
ProductName = product_name;
Category = category;
CreatedBy = created_by;
CreatedAt = created_at;
LastChangedBy = last_changed_by;
LastChangedAt = last_changed_at;
LocalLastChangedAt = local_last_changed_at;
}
} Step 8: Implement Action LogicIn the behavior implementation class:METHOD setcategory.The implementation:Reads selected productsRetrieves action parameter valueUpdates category fieldReturns updated recordsThe selected category is obtained from:keys[ … ]-%param-NewCategoryCLASS lhc_Product DEFINITION INHERITING FROM cl_abap_behavior_handler.
PRIVATE SECTION.

METHODS get_instance_authorizations FOR INSTANCE AUTHORIZATION
IMPORTING keys REQUEST requested_authorizations FOR Product RESULT result.

METHODS setCategory FOR MODIFY
IMPORTING keys FOR ACTION Product~setCategory RESULT result.

ENDCLASS.

CLASS lhc_Product IMPLEMENTATION.

METHOD get_instance_authorizations.
ENDMETHOD.

METHOD setCategory.

” Read current product records
READ ENTITIES OF zi_product_s IN LOCAL MODE
ENTITY Product
FIELDS ( ProductId Category )
WITH CORRESPONDING #( keys )
RESULT DATA(lt_products).

” Return updated records as action result
READ ENTITIES OF zi_product_s IN LOCAL MODE
ENTITY Product
ALL FIELDS
WITH CORRESPONDING #( keys )
RESULT DATA(lt_result).

result = VALUE #(
FOR ls_res IN lt_result
( %tky = ls_res-%tky
%param = ls_res )
).
ENDMETHOD.

ENDCLASS. Step 9: Create Projection Behavior DefinitionExpose the action:projection;
strict ( 2 );

define behavior for ZC_PRODUCT //alias <alias_name>
{
use create;
use update;
use delete;

use action setCategory;
} Step 10: Create Metadata ExtensionAdd UI annotations.@Metadata.layer: #CORE

annotate entity ZC_PRODUCT with
{
@ui.facet: [
{
id: ‘ProductInfo’,
type: #IDENTIFICATION_REFERENCE,
label: ‘Product Information’,
position: 10
}
]

@ui.lineItem: [{ position: 20, label: ‘Product Name’ }]
@ui.identification: [{ position: 20 }]
ProductName;

@ui.lineItem: [{ position: 30, label: ‘Category’ }]
@ui.identification: [{ position: 30 }]
Category;

} Step 11: Create Service DefinitionExpose both entities.@EndUserText.label: ‘Product Service’
define service ZSD_PRODUCT {
expose ZC_PRODUCT as Product;
expose ZI_CategoryVH as CategoryVH;
}Important:Many developers forget to expose the value help entity.Without exposing:ZI_CATEGORY_VHthe F4 dialog will not display any data. Step 12: Create Service BindingCreate:OData V4 – UIservice binding.Activate and Publish the service. ResultOnce the application is launched, users can:1. Select Products☑ P1001 Laptop
☑ P1002 Office Chair2. Click Set Category[ Set Category ]3. Action Dialog OpensSet Category

New Category [ ] 🔍4. Open Value HelpELEC Electronics
FURN Furniture
CLTH Clothing
FOOD Food & Beverages5. Choose a CategoryExample:ELEC6. ConfirmOK7. RAP Action ExecutesSelected records are updated automatically.8. List RefreshesP1001 Laptop ELEC
P1002 Office Chair ELECSuccess message:Category updated successfully ConclusionIn this blog, we explored how to implement RAP Action Parameters with Value Help using a CDS Abstract Entity.We discussed a real-world business scenario where users need to update product categories for multiple records while ensuring only valid values can be selected.By combining a CDS Value Help View, Abstract Entity, RAP Action, and Fiori Elements annotations, we were able to create a user-friendly action dialog with built-in F4 help and validation.This approach provides a reusable pattern for implementing parameterized actions in RAP and can easily be extended for approval processes, status updates, assignment actions, and many other business scenarios while maintaining a clean and scalable design. Read More Technology Blog Posts by Members articles

#SAP

#SAPTechnologyblog
